Product Overview
-
Motor Power (Peak)
3000W Mid drive Brushless Motor
-
Battery
60V, 25Ah(1500Wh)
-
Riding Range
20–50 mi (32–80 km)
-
Top Speed
Class 3: 28 Mph
Off-Road: 40 Mph -
Max Torque
200 N·m
-
Frame
High-strength Steel Pipe
-
Display
LCD Display
-
Max Load
264 lbs (120kg)
-
Net Weight
117 lbs (53 kg)
-
Charging Time
5-8 H
-
Transmission Gears
This transmission system achieves a 1:9.6 reduction ratio via two - stage speed reduction. The first stage uses a pulley (23:51 ratio), and the second uses a chain sprocket (13:56 ratio)
-
Brake System
Hydraulic Brake
-
Wheel Size & Tires
3.15×17 Inches Tires
-
Suspension
High - Performance Hydraulic Front & Rear Shock Absorbers
-
Rear Brake Light
Yes
-
Package Size
59 x 11.8 x 32 in (150 x 30 x 83 cm)
-
Suggested Rider Height
5’1”-5’11” (155-180 cm)
